Model

FS-150-12

FS-150-15

FS-150-24

FS-150-36

FS-150-48

output

DC voltage

12V

15V

24V

36V

48V

Voltage tolerance

±1%

±1%

±1%

±1%

±1%

Rated current

12.5A

10A

6.5A

4.2

3.2

Current range

0~12.5A

0~10A

0~6.5A

0~4.2A

0~3.2A

Rated power

150W

150W

156W

151.2W

153.6W

Ripple&noise

150mvp-p

150mvp-p

150mvp-p

200mvp-p

200mvp-p

DCvoltage ADJ.range

±10%

±10%

±10%

±10%

±10%

input

Voltage range

170~264VAC，255~373VDC

frequency

47~63HZ

AC current

1.8A/230VAC

efficiency

82%

82%

84%

85%

86%

Inrush current

Cold start current  45A/230VAC

Leakage current

< 3.5mA/240VAC

protection

overload

Rated output power105%~135%  start over load protection

protection type：hiccup mode，auto-recovery after fault condition is removed

over voltage

15.6~17.8V

18.6~20.8V

30.6~33.2V

42.6~44.2V

54.8~56.6V

protection type：hiccup mode，auto-recovery after fault condition is removed

environment

Working temp,humidity

-10℃~+60℃，20%~90%RH

Storagetemp,humidity

-20℃~+85℃，10%~95%RH non-condensing

Withstand vibration

10~500HZ，2G 10min/1cycle，period for 60 minutes，each axes

safety

Withstand voltage

I/P-O/P：1.5KVAC I/P-FG：1.5KVAC O/P-FG：0.5KVAC

Isolated resistance

I/P-O/P,I/P-FG,O/P-FG：100M ohms/500VDC

Fitstandard

Safety standard

Fit UL1012  IP44

EMC standard

符合EN55022，CLASSA

others

Dimension

206*125*50mm (L*W*H)

Weight/packing

0.87kg/20pcs/18.5kg/0.039m3/1.36CUFT

note

1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25℃ of ambient temperature.

2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.

3. Tolerance : includes set up tolerance, line regulation and load regulation.
